nilan Compact S Series - Air Quality Control Settings; Air Quality Regulation Modes

Subject to alterations Page 17 of 33
Air quality
In the ”Air quality” menu it is possible to choose between 3 types of regulation: Humidity, Humidity
+ CO
2
or OFF.
On the CTS602 control panel, press:
- ESC to return to the previous menu
- p to scroll upwards or downwards through the menus or to
adjust the setting of an activated menu option
- ENTER to activate a menu option
- ENTER to confirm a menu option setting
- OFF switch off the controls
- ON to switch on the controls
HOTWATER
DEFROST
FUNCTION
OFF
ENTER
ENTER
FUNCTION
”OFF”
AIR
EXCHANGE
INLET
CONTROL
SERVICE
ENTER
TEMP
.
CONTROL
RESTART
OFF
MANUAL
OFF
PRESET
OFF
ROOM
CONTROL
AIR
QUALITY
INLET
HEATING
Can be set to
:
OFF, HUMIDITY or
HUM+CO2, when is
mounted.
MODBUS
ADR 30
DATALOG
INTV 10
Figur 12: The "Air quality" Menu
