ENGLISH INSTRUCTIONS FOR USE
6 SC250 - 9100001616
07/2016
TECHNICAL DATA
Model SC250
Solution and recovery water tank capacity 1.6 US gal / 1.6 US gal (6 liters / 6 liters)
Machine size (length x width x height) 25 x 16.7 x 14.7 in (630 x 425 x 400 mm)
Cleaning width 13.4 in (340 mm)
Squeegee width
14 in (360 mm)
Rear rotating wheel diameter
3 in (75 mm)
Front wheel diameter
2 in (50 mm)
Cylindrical brush diameter 3.1 in (80 mm)
Brush pressure on the ground Max. 26.4 lb (Max. 12 Kg)
Min/max solution ow 0.04 / 0.08 gpm (0.15 / 0.3 L/min)
Sound pressure level at workstation (ISO 11201, ISO 4871, EN 60335-2-72) (LpA) 66 dB(A) ±3 dB(A)
Machine sound power level (ISO 3744, ISO 4871, EN 60335-2-72) (LwA) 83 dB(A)
Vibration level at the operator’s arms (ISO 5349-1, EN 60335-2-72) < 98.4 in/s
2
(< 2.5 m/s
2
)
Maximum gradient when working 2 %
Vacuum system motor power 0.24 hp (180 W)
Vacuum system capacity 2,132 ft H
2
O (650 mm H
2
O)
Brush motor power 180 W
Brush rotation speed 1,000 rpm
Total power draw (EN 60335-2-72) 8.5 A (0.3 kW)
IP protection class X4
Protection class (electric) III
Electrical system voltage 36 Vdc
Standard battery Lithium Ion - 36 Vdc 8Ah
Battery charger output 42 Vdc 1÷2 A
Operating time (EN 60335-2-72) 40 min
Weight with empty tanks 55 lb (25 Kg)
Gross vehicle weight (GVW) 71 lb (32 Kg)
Shipping weight 66 lb (30 Kg)
MACHINE DESCRIPTION
MACHINE STRUCTURE
1. Handlebar with control panel
2. Start/stop switch
3. Solution switch:
• 1 LED on - normal cleaning with low solution ow
• 2 LEDs on - cleaning with maximum solution ow
• 2 LEDs ashing - solution tank empty
• LEDs off - solution deactivated
4. Vacuum system push-button:
• LED on - vacuum system activated
5. Battery charging symbol
• 1 - 6 LEDs on - battery charge percentage
• 1 LED on - battery almost at (~ 10 min. remaining)
• 1 LED ashing - battery at (~ 5 min. remaining)
6. Grip handles with operator palm sensors
7. Front squeegee lifting lever
8. Handlebar inclination adjustment lever
9. Function block push-buttons:
A) Front squeegee lifted
B) Handlebar free angle
10. Park pedal:
• Lowered - parking/movement
• Raised - scrubbing/drying
11. Parking/handling front wheel
12. Recovery tank cover
13. Tanks (solution and recovery water) container
14. Solution tank ller plug
15. Tanks container lifting handle
16. Machine body/cleaning deck
17. Brush engagement/disengagement lever
18. Cylindrical brush
19. Brush oor pressure regulation knob
20. Squeegee bars
21. Debris collection tray
22. Brush drive belt compartment
23. Rear pivoting wheels
24. Folded handlebar
25. Transport handle
26. Battery and electronics compartment cover
27. Battery
28. Battery charger tray
29. Socket for battery charger
30. Serial number plate/technical data/conformity certication
A1 ENGLISH.indd 6 25/07/2016 08:29:59
