FILLING THE SOLUTION TANK
See Figure 4. Fill the solution tank with a maximum
of 50 gallons (190 Liters) of cleaning solution. Do
not fi ll the solution tank above 5 cm (2 inches) from
the bottom of the Solution Fill (32). The solution
should be a mixture of water and the proper cleaning
chemical for the job. Always follow the dilution
instructions on the chemical container label. NOTE:
EcoFlex machines can either be used conventionally
with detergent mixed in the tank or the detergent
dispensing system can be used. When using the
detergent dispensing do not mix detergent in the
tank, plain water should be used.
CAUTION!
Use only low-foaming, non-fl ammable
liquid detergents intended for machine
application. Water temperature should
not exceed 130 degrees Fahrenheit (54.4
degrees Celsius)
2"
(5cm)
SOLUTION TANK INDICATOR
See Figure 5-1. The solution tank has a level sensor with four measurement points. The Solution Level Indicator (C4) displays the level (1-4) of
the solution in the tank. Once the tank is empty the Solution Empty Indicator (C26) will fl ash on the display.
FIGURE 5-1
C4
C26
FIGURE 4
SOLUTION SHUTOFF VALVE
See Figure 5-2. A bidirectional Shutoff Valve (30) permits the solution fl ow
to be shutoff, directed toward the scrub deck, or directed toward the drain
hose. The fl ow is off when the handle is perpendicular to the body. When
the handle is turned completely in direction shown (arrow ‘A’), solution
fl ow will be directed toward Solution Filter (29) & scrub deck.
FIGURE 5-2
29
30
A
revised 10/2022
A - 20 SC6000 - 56091161 4/2016
INSTRUCTIONS FOR USEA - ENGLISH
