FORM NO. 56043071 CMAX
™
28/34ST / I-MAX
™
28/32C, BA 750/850ST, BA 750C - 9
1 Solution Tank Fill
2 Recovery Tank Cover
3Drive Paddle
4 Solution Drain Hose / Level Indicator
5 Recovery Drain Hose
6 Squeegee Adjustment Bolt
7 Squeegee Blade Latch
8 Squeegee
9 Machine Battery Connector
10 Solution Flow Control Knob
11 Speed Limit Control Knob
12 Wheel Drive Circuit Breaker (30 Amp)
13 Control Circuit Circuit Breaker (5 Amp)
14 Brush Deck
15 Operator Control Handle
16 Operator Hand Brake (optional)
17 Squeegee Lever
18 Solution Filter
19 Hopper (Cylindrical Only)
20 Idler Assembly (Cylindrical Only)
21 Tie Down Locations (4)
KNOW YOUR MACHINE
1
1
2
3
4
5
7
8
9
10
11
12
13
14
15
16
6
17
18
19
20
21
21
