4 - FORM NO. 56043071 CMAX
™
28/34ST / I-MAX
™
28/32C, BA 750/850ST, BA 750C
Model designation: (A)=CMAX 28ST & BA 750ST, (B)=BA 850ST, (C)=I-MAX 28C & BA 750C, (D)=I-MAX 32C, (E)=CMAX 34ST
General Specifications ABCDE
24V (disc) 24V (disc) 36V (cylindrical) 36V (cylindrical) 36V (disc)
Machine Length (English) 64 in. 65 in. 67.5 in. 67.5 in. 67.5 in.
Metric 163cm 165cm 172cm 172cm 172cm
Machine Width with Squeegee (English) 36.25 in. 45 in. 36.25 in. 45 in. 45 in.
Metric 92cm 114cm 92cm 114cm 114cm
Machine Width w/out Squeegee (English) 30 in. 35.5 in. 31 in. 35 in. 35.5 in.
Metric 76cm 90cm 79cm 89cm 90cm
Machine Height 44 in. (112cm) 44 in. (112cm) 44 in. (112cm) 44 in. (112cm) 44 in. (112cm)
Machine Net Weight* (English) 495 lbs. 535 lbs. 535 lbs. 619 lbs. 579 lbs.
Metric 225kg 243kg 243kg 281kg 263kg
Machine Gross Weight** (English) 1,100 lbs. 1,120 lbs. 1,350 lbs. 1,350 lbs. 1,350 lbs.
Metric 499kg 508kg 612kg 612kg 612kg
Cleaning Width (scrubbing path) (English) 28 in. 33.5 in. 28 in. 32 in. 33.5 in.
Metric 71cm 85cm 71cm 81cm 85cm
Coverage Rate Per Hour (theory) (English) 37,100 ft
2
44,388 ft
2
37,100 ft
2
46,200 ft
2
44,388 ft
2
Metric 3,447m
2
4,124m
2
3,447m
2
4,292m
2
4,124m
2
Brush Diameter (qty of 2) 14 in. (36cm) 17 in. (43cm) 5.75 in. (15cm) 5.75 in. (15cm) 17 in. (43cm)
Brush Core Length (qty of 2) (Cylindrical) – – 27 in. (69cm) 31 in. (79cm) –
Brush Speed (RPM) 220 220 900 900 220
Brush Pressure Variable, (English) 25-250 lbs. 25-300 lbs. 25-250 lbs. 25-250 lbs. 25-300 lbs.
Metric 11-113kg 11-136kg 11-113kg 11-113kg 11-136kg
Solution Tank Capacity 24 gal. (91l.) 24 gal. (91l.) 30 gal. (114l.) 30 gal. (114l.) 30 gal. (114l.)
Recovery Tank Capacity 24 gal. (91l.) 24 gal. (91l.) 30 gal. (114l.) 30 gal. (114l.) 30 gal. (114l.)
Vacuum Water Lift (Sealed) 56 in. 56 in. 68 in. 68 in. 68 in.
(Open Hole Adapter 1") 9 in. 9 in. 13 in. 13 in. 13 in.
Sound pressure level
as per ISO 3744 (at operator) 70 dB(A) 70 dB(A) 70 dB(A) 70 dB(A) 70 dB(A)
Transport Speed (Fwd. Maximum) 265 FPM 265 FPM 265 FPM 265 FPM 265 FPM
Metric 81 m/min 81 m/min 81 m/min 81 m/min 81 m/min
Transport Speed (Rev. Maximum) 140 FPM 140 FPM 140 FPM 140 FPM 140 FPM
Metric 43 m/min 43 m/min 43 m/min 43 m/min 43 m/min
Power Source (Batteries) STD (4) 6V/238AH (4) 6V/238AH (6) 6V/238AH (6) 6V/238AH (6) 6V/238AH
Battery Weight (each) 66lbs. (29.9kg) 66lbs. (29.9kg) 66lbs. (29.9kg) 66lbs. (29.9kg) 66lbs. (29.9kg)
Battery Compartment Size
Height (Max.) 13 in. (33cm) 13 in. (33cm) 15 in. (38cm) 15 in. (38cm) 15 in. (38cm)
Width (Max.) 15 in. (38cm) 15 in. (38cm) 21.37 in. (54cm) 21.37 in. (54cm) 21.37 in. (54cm)
Length (Max.) 24 in. (61cm) 24 in. (61cm) 23.5 in. (59cm) 23.5 in. (59cm) 23.5 in. (59cm)
Battery Chargers – see Electrical System Battery Section
Wheel Drive Motor*** .5 hp, 552 watt .5 hp, 552 watt .5 hp, 540 watt .5 hp, 540 watt .5 hp, 540 watt
Vacuum Motor .75 hp, 570 watt .75 hp, 570 watt .75 hp, 570 watt .75 hp, 570 watt .75 hp, 570 watt
Brush Drive Motors*** (2 each) .75 hp, 792 watt .75 hp, 792 watt .75 hp, 684 watt .75 hp, 684 watt .75 hp, 792 watt
Machine Current (Average) 75 Amps 90 Amps 90 Amps 90 Amps 90 Amps
*Net Weight: Standard machine without options, empty solution and recovery tanks, without removable scrub brushes and no batteries installed.
**Gross Weight: Standard machine without options, full solution tank and empty recovery tank, with removable scrub brushes and 305 AH batteries.
***Listings for watts are maximum values.
