32 - FORM NO. 56043071 CMAX
™
28/34ST / I-MAX
™
28/32C, BA 750/850ST, BA 750C
SCRUB BRUSH SYSTEM
+
+
+
–
–
–
FRONT
Belt
Brush
Brush
Right MotorLeft Motor
Belt
Counter-clockwise
rotation from
shaft end
Counter-clockwise
rotation from
shaft end
FIGURE 6
FIGURE 5
13/16“ to 7/8” (20-22 mm)
FRONT
