Nilfisk-Advance CMAX 28/34ST User Manual

FORM NO. 56043071 CMAX
™
28/34ST / I-MAX
™
28/32C, BA 750/850ST, BA 750C - 29
SCRUB BRUSH SYSTEM
Motor wiring for: CMAX
™
28ST, CMAX
™
34ST, BA 750ST and BA 850ST
*Right and left are identified as seen from the rear of the machine.
FIGURE 3
+
+
+
+
-
+
-
+
Right*
Brush
Mot or
Left*
Brush
Mot or
These Two Terminals
are Connected with a
Jumper Plate (inset)
-
+
+
-
These Two Terminals
are Connected with a
Jumper Plate (inset)
(+) (-)
Jumper Plate
WHT BLK
+-
+-
FRONT
Negative lead
from right motor
Negative lead
from left motor
Positive lead from right motor
