102Service Manual – SC6000 34 - Scrub System, Disc
Specications
Parameter Range
Brush Contactor Coil Resistance 189 Ω
Brush Motor Amperage 4 amps per motor at 100%
Lift Actuator Amperage Up: 4.1A initial, then 2.6A
Down: 0.9-1.2A
Special Tools
Actuator Test Kit
The actuator test kit (Pn 56407502) is used to
manually control an actuator removed from the
machine, but powered from a 36-volt battery. It
contains alligator clips to connect to the battery, a
reversing power switch, and a cable connector. If
your test kit is prior to Rev E, you will also need
an adapter cable (Pn 56384816) to connect between
the tester and the actuator. This adapter cable is
included in Rev E and above.
