111Service Manual – SC6000 34 - Scrub System, Cylindrical
8. Remove the lower retaining clip and pin (F) from the
actuator.
9. Taking care to not rotate the leadnut with respect to the
actuator body, lift the actuator out from above. You may
need to rotate the whole assembly clockwise slightly to
clear the motor-side of the actuator from the battery bay
panel.
10. As necessary, perform the Lift Actuator Limit
Adjustment described on page 106.
F
