139Service Manual – SC401, SCRUBTEC 344 34 - Scrub System, Disc
Component Locations
Figure 2:
Brush deck support
Brush
Machine straight
forward movement
adjusting knob
Disc brush deck
Brush motor (M1) Deck raising levers
Figure 3:
Drive hub
