159Service Manual – SC401, SCRUBTEC 344 40 - Recovery System
Wiring Diagram
MAIN MACHINE
CONTROLLER
RELAY (ES1)
VACUUM MOTOR
FUSE (F2)
VACUUM
MOT
OR (M2)
0V
B+ 24V (POWER)
OUT2+
OUT2-
B-
0V
M2
Vacuum output +
Vacuum output -
Figure 1:
