23Service Manual – SC401, SCRUBTEC 344 03 - General Information
Rear/Left Machine View
Figure 7:
Front wheels
Brush deck
lifting/lowering
pedal
Tank lifting
handle
Solution drain
and level check
hose
Squeegee lifting/
lowering pedal
Drive handlebar
Control panel
Recovery water
drain hose
Power supply
cable holder
Power supply
cable holder
Serial number
plate/technical
data/conformity
certication
Power supply
cable
Squeegee
adjusting knob
Squeegee
mounting
handwheels
Recovery tank
cover
Recovery tank
Squeegee
vacuum hose
