152Service Manual – SC401, SCRUBTEC 344 38 - Squeegee System
Component Locations
Figure 1:
Squeegee adjusting
knob
Lower squeegee
support
Mounting
handwheels
Squeegee lifting/
lowering pedal
Spring
Squeegee blades
Impact deection
wheel
Upper squeegee
support
