86Service Manual – SC401, SCRUBTEC 344 14 - Wheel System, Non-Traction
Specications
Description / Model
SC401, SCRUBTEC 344
No Drive
Front wheel diameter
7.8 in (200 mm)
Front wheel specic pressure on the oor (*)
116 psi (0,8 N/mm
2
)
Rear wheel diameter 3,1 in (80 mm)
Rear wheel specic pressure on the oor (*) 116 psi (0,8 N/mm
2
)
Maximum gradient when working 2%
(*) Machines have been tested under the following conditions:
◦ Battery maximum size (Battery)
◦ Maximum brush and squeegee size
◦ Full detergent tank
◦ Optional equipment installed
◦ Wheel weight checked
◦ Print on the oor checked on cement for each single wheel
◦ Result expressed as maximum value for both front and rear wheels
