42Service Manual – SC401, SCRUBTEC 344 04 - Control System - Battery
Main Machine Controller (EB1) (continues)
(N) Drive wheels controller connection (JJ209 D4).
Figure 18:
123 123
N
N
(O) Main machine controller connection (J104 BATTERY/RELAY).
Figure 19:
1
2
3
O
O
(P) Ignition key connection (J101 KEY).
Figure 20:
1
2
P
