Appendix — Specifications
Table 10: Specifications
Parameter PTR E Comments
Appearance Anodized silver + porcelain white + lime green Color kit optional
Main materials Magnesium alloy + aluminum alloy + LEXAN resin —
Gross weight 23.5 kg (51.8 lbs) —
Vehicle size
390 × 590 × 1100–1400 mm
(15.4 × 23.2 × 43.3–55.1 inches)
L × W × H
Weight without operation bar 22.0 kg (48.5 lbs)
Does not include
handlebar nor charger
Size without operation bar
390 × 590 × 400 mm
(15.4 × 23.2 × 15.7 inches)
Does not include
handlebar nor charger
Recommended rider height
The operation bar is available in 3 sizes.
Large: 1.8–2.1 m (5'7"–6'10')
Standard: 1.5–1.9 m (5'0"–6'2")
Small: 1.3–1.7 m (4'3"–)
Large and small
operation bars must be
purchased separately.
Mainframe package size
620 × 444 × 470 mm
(24.4 × 17.5 × 18.5 inches)
Operation bar package size
—
1140 × 140 × 95 mm
(44.9 × 5.5 × 3.7 inches)
—
