1.3.13.1 Battery
The battery is a conventional 12-volt type
with a positive cable and a negative ground
cable. The cables have protective boots at
the battery end.
1.3.13.2 Alternator
Electrical power is supplied by a belt-driven
alternator mounted on the front of the en
-
gine. It produces three-phase alternating
current and voltage, rectified to DC by a
full-wave rectifier bridge using six diodes.
The alternator does not require a cutout re
-
lay.
1.3.13.3 Current Regulator
The current regulator is part of the alterna-
tor assembly. It determines output current
according to load, such as headlights, rear
lights, etc.
1.3.13.4 Starter
The starter motor is a gear-reduction type
mounted on the automatic transmission
housing at the rear of the engine. The
starter motor is used to turn the engine fast
enough to start the engine.
1.3.13.5 Lights and Accessories
Two head lights are on the front of the trac
-
tor. The stop/tail lights and rear backup
lights are in the rear body. The backup
lights can also be used as work lights (there
is a separate switch for this purpose).
M200 MB4 Tow Tractor Manual No. 42975
PAGE 1-4
JULY 15, 2001
