NMC-WOLLARD MB-4 200-DF - Suggested Wrenching Torque for Tapered Pipe Thread 1

General Information
10
14
DPSG,YZ07927,8 –19–30APR99–1/1
SUGGESTED WRENCHING TORQUE FOR
TAPERED PIPE THREAD
1
TAPERED PIPE THREAD WITH SEALANT CHART
Thread Size N• m lb-ft
1/16-27 UNF 15 10
1/8-27 UNF 20 15
1/4-18 UNF 25 20
3/8-18 UNF 35 25
1/2-14 UNF 45 35
3/4-14 UNF 60 45
1-11 1/2 UN 75 55
1-1/4-11 1/2 UN 95 70
1-1/2-11 1/2 UN 110 80
2-11 1/2 UN 130 95
TAPERED PIPE THREAD WITHOUT SEALANT CHART
Thread Size N•m lb-ft
1/16-27 UNF 20 15
1/8-27 UNF 25 20
1/4-18 UNF 35 25
3/8-18 UNF 45 35
1/2-14 UNF 60 45
3/4-14 UNF 75 55
1-11 1/2 UN 90 65
1-1/4-11 1/2 UN 110 80
1-1/2-11 1/2 UN 130 95
2-11 1/2 UN 160 120
1
SUGGESTED WRENCHING TORQUE FOR TAPERED PIPE THREAD
charts meet Funk Engineering Procedures Manual Torque Specifications
FEP 14.4.
CTM195 (28JUL99) 10-14 2000 Series Transmission
072899
PN=28
