2. Assemble valve stems, if not already
done.
3. Slide wheel over final drive carrier and
onto wheel pilot.
4. Install capscrews by hand to insure
screws are not cross-threaded.
If using a power wrench,
first hand engage capscrews to prevent
stripping.
5. Do not start lug nuts with power tools or
cross threading may result.
6. If using a power wrench, first hand-en
-
gage capscrews to prevent stripping. Op-
erate wrench slowly to prevent damage to
threads.
7. Tighten gradually in an alternating pattern
to final torque valve.
MODEL 200 TRACTORS
WHICH
WHEEL
STUD SIZE TIGHTENING
TORQUE (DRY)
Front 22mm 400 ft-lbs.
Rear 22mm 400 ft-lbs.
8. Always recheck lug nut torque one hour
after mounting wheel and tire assembly.
Failure to do so may result in loose
wheels and/or broken wheel studs.
9. Lower tractor and remove jack stands
and jacks from beneath tractor.
10. Run unit and check wheels after one hour
and periodically thereafter to be sure
wheels are set.
PAGE 9-7
JULY 31, 2006
M200 MB4 Tow Tractor Manual No. 42975
