Operation
BDA−N6−ALL−US−1.0 www.noax.com Page 17 of 28
4.1.2 Display area
The functions of the operating and display elements can be modified in the software’s setup. The
following overview describes the functions in the factory settings.
Light−emitting diode Function
POWER Lights up as soon as the Industrial PC is turned on.
INPUT Lights up at valid entry
HDD Lights up when the hard drive is accessed.
OK Lights up after the Industrial PC has successfully completed the
internal function test and all functions are in order.
ERROR Lights up when a problem or an error occurrs at the Industrial
PC.
í See troubleshooting chapter 6
4.1.3 Key area
Key Function
BRIGHTNESS + Increase brightness
− Decrease brightness
CONTRAST + Not used!
− Not used!
ON−OFF I Turn on the Industrial PC or. CFL back light, trigger the hard reset
O
Shut off the Industrial PC or CFL back light.
4.2 Operation
í The functions of the operating and display elements can be restricted or deactivated in the softwa-
re’s setup. The following overview describes the functions in the standard settings. This software
can be downloaded on the Internet.
Function Standard settings
Turn on the Industrial PC " Press the ON (I) for at least one second
Turn off the Industrial PC " Press OFF (O) for at least 5 seconds
Set the display’s brightness " To change the brightness by one level, tap the [+] or [−]
key briefly
" To continuously change the brightness, keep the [+] or [−]
key pressed down
Trigger the hard reset " Press the ON (I) key for more than 5 seconds
4.2.1 CFL back light
The integrated CFL back light will dim to an adjustable, reduced brightness 3 minutes after the last
time a key has been pressed or the display has been touched.
Function Standard settings
Dim " 3 minutes after a key has been pressed or the screen has
been touched
Reactivate " Press any key on the external PS2 keyboard (only PS2, not
USB)
" Press the ON key
" Press the touch surface
" Moving a PS/2 mouse
í You can reactivate the back light by briefly pressing the key ON (I).
