Power supplies
BDA−N6−ALL−US−1.0 www.noax.com Page 9 of 28
2.2 External power supply NEMA4 (IP65)
Fig. 17 External power supply NEMA4
Fig. 18 Mounting holes
198
174
145
130
14.5
4.5
at least 220
144
The external power supply with a degree of
protection NEMA4 can be mounted directly
on the wall, for example, using the mounting
holes.
To mount the external power pack, transfer
the distances between the drill holes shown in
the drawing to the surface provided for at-
tachment.
