Technical data
BDA−N6−ALL−US−1.0 www.noax.com Page 23 of 28
7.5 Mainboard
Version A Equipment
Mobile Celeron with 400 MHz
Temperature monitoring of the CPU
maximum 512 MB DRAM (SO−DIMM base)
Real−time clock
CMOS−RAM
VGA controller C&T69030 with 4MB SD−RAM video memory
Simultaneous mode TFT display and monitor, external VGA con-
nection
Version B Equipment
Same as version A,
however:
Mobile Pentium with 700 MHz
Version C Equipment
Same as version B
and additionally:
Compact flash slot
PC card slot
Sound
Firewire IEEE 1349
í For which board is in your Industrial PC see page 4.
7.6 Technical data IPC
Rated input voltage 24 V
Maximum input voltage: 18 − 32 V
Input current: type. 1.5 A at 24 V (depends on the stage of completion)
Power consumption during operation approx. 36 W
Standby power consumption: approx. 1 W
7.7 Additional cards in the ISA/PCI slot
Two combi slots are available for ISA / or PCI cards. You can insert cards with a maximum length
of 7.87 inch (200 mm).
Maximum power consumption at 5 V: 1.5 A (per card)
Maximum power consumption at 12 V: 1.0 A (per card)
Both cards may not exceed the maximum power consumption of 20 W! Please observe the
maximum currents at all times! Cards installed into the two combi slots raise the internal tem-
perature and lower the maximum specified ambient temperature!
