MPLS and RSVP-TE
278
MPLS Guide
© 2022 Nokia.
Use subject to Terms available at: www.nokia.com
3HE 18686 AAAB TQZZA
Up Thresholds(%) : 0 15 30 45 60 75 80 85 90 95 96 97 98 99 100 *
Down Thresholds(%): 100 99 98 97 96 95 90 85 80 75 60 45 30 15 0 *
IGP Update Pending: No
Next Update : N/A
No Neighbors.
* Indicates Inherited Values
-------------------------------------------------------------------------------
A: ALU-12#
Table 26 Router RSVP-TE Interface Detail Field Descriptions
Label Description
Interface The name of the IP interface
Port ID The physical port bound to the interface
Admin State Down — the RSVP-TE interface is administratively disabled
Up — the RSVP-TE interface is administratively enabled
Oper State Down — the RSVP-TE interface is operationally down
Up — the RSVP-TE interface is operationally up
Active Sessions The total number of active RSVP-TE sessions on this interface
Active Resvs The total number of active RSVP-TE sessions that have reserved
bandwidth
Total Sessions The total number of RSVP-TE sessions on this interface. This
count includes sessions that are active as well as sessions that
have been signaled but a response has not yet been received.
Subscription The percentage of the link bandwidth that RSVP-TE can use for
reservation. When the value is zero (0), no new sessions are
permitted on this interface.
Port Speed The speed on the interface
Total BW The amount of bandwidth in megabits per second (Mbps)
available to be reserved for the RSVP-TE protocol on this
interface
Aggregate Indicates whether aggregate messages are sent. Aggregate
messages are used to pack multiple RSVP messages into a
single packet to reduce the network overhead. When the value is
true, RSVP negotiates with each neighbor and gets consensus
before sending aggregate messages.
