Nokia Flexi Zone Micro High Power 2x20 W BTS - Figure 9 Correct Bracket Alignment; Figure 10 Installing the BTS on a Wall

g
Note: Beforetighteningthescrewsmakesurethat:
•
thestaticmountingbracketissecurelycaptivatedintheinterfacebracket'sslot.
•
tabsontheinterfacebracketarecaptivatedbythebacksurfaceofthestatic
mountingbracket.
Figure9
Correctbracketalignment
Tabson
interfacebracket
Tabon
staticbracket
Slotininterfacebracket
Figure10
InstallingtheBTSonawall
InstallingFlexiZoneMicroBTS InstallingandCablingFlexiZoneMicroHighPower
2x20WBTS
16 DN09229011 Issue:02
 
