Nokia Flexi Zone Micro High Power 2x20 W BTS User Manual

1.3 Installing Flexi Zone Micro BTS (FWHR) on a
horizontal pole
TheproceduredescribestheinstallationonahorizontalpolethatisspecificforFWHR.
Purpose
UsetheFlexiZoneWallandPoleMountingBracket(FMWA)(472858A)andbandstraps
toinstallFlexiZoneMicroBTSonapole.Thebandstrapsdependonthechosenpole
diameter.Thewidthofthebandstrapsshouldbelessthan¾"toproperlyfitintotheslots
ofthemountingbracket.
Before you start
f
CAUTION! Risk of personal injury.
Ensurethattheselectedbandstrapscansustainthedeviceunderrequired
circumstances.
Theselectedbandstrapsshouldberatedforoutdooruseandbecapableofsecuring
theBTSweight.Acertifiedstructuralengineershouldinspectandapprovethe
mountingpoleandhardwarepriortoinstallation.
w
NOTICE:FlexiZoneMicroBTSequipmentmustbeinstalledbytrainedandqualified
servicepersonnelinaccordancewithalllocalcodesandrequirements.
w
NOTICE:FlexiZoneMicroBTSequipmentisintendedforinstallationinarestricted
accesslocationorequivalent.
w
NOTICE:TheBTSinterfacepanelshouldalwaysfacetheground.Anyotherinstallation
positionmightcauseoverheatingandpossibledamagetotheBTS.
Figure20
FlexiZoneMicroBTS(FWHR)interfacepanel
RF
BACKHAUL
ST
A
TUS
BHC
BHB
AC
POWER
BLUET
OOTH
InterfacepanelsideofBTS
InstallingFlexiZoneMicroBTS InstallingandCablingFlexiZoneMicroHighPower
2x20WBTS
24 DN09229011 Issue:02
 
