Nokia Flexi Zone Micro High Power 2x20 W BTS - Figure 18 Correct Bracket Alignment; Figure 19 Installing the BTS on a Vertical Pole

g
Note: Beforetighteningthescrewsmakesurethat:
•
thestaticmountingbracketissecurelycaptivatedintheslotintheinterfacebracket.
•
tabsontheinterfacebracketarecaptivatedbythebacksurfaceofthestatic
mountingbracket.
Figure18
Correctbracketalignment
Tabson
interfacebracket
Tabon
staticbracket
Slotininterfacebracket
Figure19
InstallingtheBTSonaverticalpole
InstallingandCablingFlexiZoneMicroHighPower
2x20WBTS
InstallingFlexiZoneMicroBTS
Issue:02 DN09229011 23
 
