Nokia Flexi Zone Micro High Power 2x20 W BTS User Manual

1 Installing Flexi Zone Micro BTS
1.1 Installing Flexi Zone Micro BTS (FWHR) on a wall
TheproceduredescribestheinstallationonawallthatisspecificforFWHR.
Purpose
UsetheFlexiZoneWallandPoleMountingBracket(FMWA)(472858A)toinstallFlexi
ZoneMicroBTS(FWHR)onawall.
Before you start
f
CAUTION! Risk of personal injury.
Ensurethatthewallinstallationsurfaceandselectedfastenerscansustainthedevice
underrequiredcircumstances.Evaluationofthewallstructureandfasteninghardware
typeshouldbedonebyastructuralengineer.
w
NOTICE:FlexiZoneMicroBTSequipmentmustbeinstalledbytrainedandqualified
servicepersonnelinaccordancewithalllocalcodesandrequirements.
w
NOTICE:FlexiZoneMicroBTSequipmentisintendedforinstallationinarestricted
accesslocationorequivalent.
w
NOTICE:TheBTSinterfacepanelshouldalwaysfacetheground.Anyotherinstallation
positionmightcauseoverheatingandpossibledamagetotheBTS.
Figure1
FlexiZoneMicroBTS(FWHR)interfacepanel
RF
BACKHAUL
ST
A
TUS
BHC
BHB
AC
POWER
BLUET
OOTH
InterfacepanelsideofBTS
WhenselectingalocationtomounttheBTS,keepinmindthefollowing:
InstallingandCablingFlexiZoneMicroHighPower
2x20WBTS
InstallingFlexiZoneMicroBTS
Issue:02 DN09229011 9
 
