Nokia Flexi Zone Micro High Power 2x20 W BTS - Figure 22 Disassembling the Mounting Bracket

Figure22
Disassemblingthemountingbracket
Interfacebracket
Staticbracket
2 Fix the interface bracket to the Flexi Zone Micro BTS using two M6 cap screws
and washers included with the mounting bracket.
Tightenthescrewsto5.1Nm(3.8ft-lb).
InstallingandCablingFlexiZoneMicroHighPower
2x20WBTS
InstallingFlexiZoneMicroBTS
Issue:02 DN09229011 27
 
