Nokia N96 User Manual

● WPA/WPA2
— Select the means of authentication:
EAP to use an extensible
authentication protocol
(EAP) plug-in, or
Pre-shared key
to use a password.
Complete the appr
opriate settings:
● EAP plug-in settings
— Enter the settings as
your service provider instructs.
● Pre-shared key
— Enter a password. The same
password must be entered on the WLAN access
point device.
● WPA2 only mode
— Only WPA2 enabled devices
are allowed to establish a connection in this mode.
Advanced WLAN settings
Select
Options >
Advanced settings
and from the
following:
● IPv4 settings
— Enter the IP address of your
device, the subnet IP address, the default gateway,
and the IP addresses of the primary and secondary
DNS servers. Contact your internet service provider
for these addresses.
● IPv6 settings
— Define the type of DNS address.
● Ad-hoc channel
(only for
Ad-hoc) — To enter a
channel number (1-11) manually, select
User
defined
.
● Proxy server address
— Enter the address for the
proxy server.
● Proxy port number
— Enter the proxy port
number.
Packet data settings
Press , and select
Tools >
Settings >
Connection
> Packet data
.
The packet data settings a
ffect all access points using
a packet data connection.
● Packet data connection
— If you select
When
available
and you are in a network that supports
packet data, the device registers to the packet data
network. Starting an active packet data connection
(for example, to send and
receive e-mail) is quicker.
If there is no packet data coverage, the device
periodically tries to establish a packet data
connection. If you select When needed
, the devic
e
uses a packet data connection only if you start an
application or action that needs it.
● Access point
— The access point name is needed
to use your device as a packet data modem to a
compatible computer.
● High speed packet access
— Enable or disable th
e
use of HSDPA (network service) in UMTS networks.
Wireless LAN settings
Press , and select
Tools >
Settings >
Connection
> Wireless LAN
.
© 2008 Nokia. All rights reserved.
165
Security settings for 802.1x and WPA/WPA2

Nokia N96 Specifications

General

Panel type	TFT
Display diagonal	2.8 \
Display resolution	240 x 320 pixels
Display number of colors	16.78 million colors
Internal memory	16 MB
Front camera type	Single camera
Rear camera resolution	2592 x 1944 pixels
USB 2.0 ports quantity	1
Multimedia Messaging Service (MMS)	Multimedia Messaging Service (MMS) is a standard way to send messages that include multimedia content to and from a mobile phone over a cellular network
Audio formats supported	AAC, eAAC+, MP3, WMA
Image formats supported	EXIF
Ringer type	Polyphonic
Form factor	Slider
Product color	Gray
Talk time (2G)	150 h
Battery capacity	950 mAh
Standby time (2G)	200 h
Continuous audio playback time	14 h
Continuous video playback time	5 h
2G standards	HSCSD
Data network	wcdma
Bluetooth version	2.0+EDR

Weight and Dimensions

Depth	20 mm
Width	55 mm
Height	103 mm
Weight	125 g
