7.3. DisplayCablingConnections( 2018+)

Figure33:DisplayCablingOverview(2018+)
1. ConnectcableC40tothe6‐pindisplaybusconnectorontheHCM1(Figure32).

Figure34:DisplayBusLocation
2. ConnectcableC40toa3‐waycoupler(E10).
3. Connectthepowercable(C30)tothe3‐waycoupler(E10).ConnecttheotherendofC30tothepower 
studsattherearofthemachine(Figure35).
DisplayBus
