Page25
Visitwww.solutions.norac.caformoresystem
installationandtroubleshootinginfo.

Figure39:PowerStudLocation
5. ConnectcableC40betweena2‐waycouplerwithterminator(E20)andthe3‐waycoupler(E10).
6. ConnectcableC35tothe2‐waycouplerwithterminator(E20).TeetheCANbusinterfacecable(C35)into
thesprayerCANbusattherearofthemachine.


Figure40:CANbusInterfaceLocation


 
