Norac UC4+ - Boom Geometry Tuning

23
6.1.8 STEP 8: Boom Geometry Tuning
• Do not activate any hydraulic functions during this step.
↓ ↓Release
⇒
↓Switch
• Release the "AUTO (YES)" switch to continue.
Exit cab
↓
⇒
↓push
⇒
↓boom tip
⇒
near
t
o
⇒
↓ground
⇒
↓& let go
• Exit the cab of the machine and manually push either boom tip near to
the ground for a moment and then let go. *
CAUTION!:
DO NOT WALK NEAR THE SENSORS WHEN APPROACHING
THE BOOM. STAY AT LEAST 3 FEET FROM THE SENSOR IN
ORDER NOT TO INDUCE MEASUREMENT ERROR.
• Push either boom tip such that the tip moves at least 15 inches (more if
you can).
• Once the control panel has detected your sprayer's geometry, the next
menu prompt will appear.
• Toggle "SETUP (NO)" or toggle and hold "AUTO (YES)" at this
menu to accept the default parameters and continue.
*This step is not applicable to system type GN2
