6.1.7 STEP 7: Sensor Detect
Level
↓
⇒
↓booms at
⇒
↓35 inch
⇒
height
⇒
↓Proceed?
• If you have main boom roll control, manually level the boom.
• Position all other boom sections such that the nozzles are 90 cm (35
inches) from the ground.
• Toggle "AUTO (YES)" to continue.
Hold
↓
⇒
↓AUTO
⇒
↓until
⇒
↓Done
• Hold the "AUTO (YES)" switch to begin the sensor detect sequence.
During the procedure you must hold the "AUTO (YES)" switch. If
"AUTO (YES)" is released, simply toggle and hold again to continue
the procedure.
• The control panel reads the serial numbers of all connected sensors.
↓3 Sensrs ↓
• Number of sensors found is displayed. This should match the number of
sensors on your system. If it does not, turn off the control panel and
ensure that all sensors are plugged in and operating.
• The control panel indicates the progress through the detection stage.
