Norac UC4+ - Wiring Test

21
6.1.6 STEP 6: Wiring Test *
⇒
↓Press
⇒
↓Left Up
• Use the sprayer's manual controls to move the left boom up.
• If the wrong boom moves or if the direction is incorrect, stop the setup.
Consult the UC4+ Installation Manual to check the hydraulic plumbing
and electrical wiring of your system. Turn on the control panel again to
resume the system setup.
↓Left↑ OK
• Control panel confirms the wiring is correct.
• Continue the process with the remaining booms, as shown below.
Lower Left
Boom
⇒
↓Press
⇒
↓Left Dn
Raise Right
Boom
⇒
↓Press
⇒
↓Rght Up
Lower Right
Boom
⇒
↓Press
⇒
↓Rght Dn
** Raise Main
Boom
⇒
↓Press
⇒
↓Main Up
** Lower Main
Boom
⇒
↓Press
⇒
↓Main Dn
* Some sprayer types do not support a wiring test or they may support a
different style of test. If you do not see any of the messages in this step, simply
continue as prompted by the panel.
** These prompts are only shown for sprayer types that support automatic
main boom height control.
