Nord Drivesystems B1000 Series User Manual

3. Storage, Preparation,
Installation
-14- B1000 www.nord.com
Figure 3-8: Mounting the rubber buffer (Option G and/or VG) on parallel shaft gear units
Figure 3-9:
Attaching the torque support on bevel gear and worm gear units
Tighten the bolts on the rubber buffer and the torque support to the correct torque (see Section 6.2
for torque values) and secure to prevent loosening (e.g. Loctite 242, Loxeal 54-03).
Always support torque support on both sides!
