NORDAC FLEX (SK 200E ... SK 235E) – Users Manual for Frequency Inverters
156 BU 0200 en-3118
Pos: 37 4 /Anlei tung en/El ektr onik/FU und Star ter/5 . Par ameter/ Par ameter aufli stung (P000 .. .)/P3 00-P3 99/Par amet er P301 – Drehgeber Auflösung @ 0\mod_1327591605104_388.docx @ 8511 @ @ 1
P301
Rotary encoder res.
(Rotary encoder resolution)
0 ... 17
{ 6 }
Input of the pulse-count per rotation of the connected encoder.
If the encoder rotation direction is not the same as the FI, (depending on installation and wiring),
this can be compensated for by selecting the corresponding negative pulse numbers 8...16.
0 = 500 pulses
1 = 512 pulses
2 = 1000 pulses
3 = 1024 pulses
4 = 2000 pulses
5 = 2048 pulses
6 = 4096 pulses
7 = 5000 pulses
8 = -500 pulses
9 = -512 pulses
10 = -1000 pulses
11 = -1024 pulses
12 = -2000 pulses
13 = -2048 pulses
14 = -4096 pulses
15 = -5000 pulses
16 = -8192 pulses
17 = 8192 pulses
NOTE:
(P301) is also significant for position control via incremental encoders. If an incremental encoder
is used for positioning (P604=1), the setting of the pulse number is made here.
POSICON Supplementary Manual)
