4 Commissioning
BU 0200 en-3118 105
Pos: 23 1 /Anlei tung en/El ektr onik/FU und Star ter/4 . Inbetriebnahme/SK 1xxE, SK 2xxE, -FDS/Inbetriebnahme Gerät/Konfiguration_01 [SK 2xxE] @ 1\mod_1343218853713_388.docx @ 37328 @ 3 @ 1
4.3.2 Configuration
Changes to individual parameters are usually necessary for operation.
However, configuration can be carried out to a limited extent with the by means of the integrated 8-
pole DIP switch (S1).
Information
Configuration via DIP switch
Mixing of DIP switch configuration and (software) parameterisation should be avoided.
Pos: 23 2 /Anlei tung en/El ektr onik/FU und Starter/4. Inbetriebnahme/SK 1xxE, SK 2xxE, -FD S/In betrie bnahm e Gerät /Para metri erung [SK 1x 0E, SK 2x xE] @ 1\mod_1343219106227_388.docx @ 37352 @ 4 @ 1
4.3.2.1 Parameterisation
The use of a ParameterBox (SK CSX-3H / SK PAR) or the NORD CON software is required in order to
adapt the parameters.
Parameter group Parameter numbers Functions Comments
Basic parameters
P102 … P105
Ramp times and frequency
limits
Motor data
P201 … P207, (P208)
Data on motor rating plate
P220, Function 1
Measure stator resistance
Value is written to P208
alternatively
P200
Motor data list
Selection of a 4-pole standard
NORD motor from a list
alternatively
P220, Function 2
Motor identification Complete measurement of a
connected motor
Prerequisite: Motor no more
than 3 power levels less than
the frequency inverter
Control terminals P400, P420 Analogue and digital inputs
Pos: 23 3 /Anlei tung en/El ektr onik/FU und Star ter/4 . Inbe trieb nahme/ SK 1xx E, SK 2x xE, -FDS/I nbe triebn ahme G erät/ Param etrier ung _01 (INFOR MATION -W erksei nst ell ung ) [ SK 2 xxE] @ 8\mod_1441360759202_388.docx @ 240130 @ @ 1
Information
Factory settings
Prior to commissioning, it should be ensured that the frequency inverter is in its factory settings (P523).
If configuration is carried out at parameter level, the DIP switches (S1) must also be set to the "0" ("OFF")
position.
