1.8 Type code / nomenclature
Unique type codes have been defined for the individual modules and devices. These provide
individual details of the device type and its electrical data, protection class, fixing version and special
versions. A differentiation is made according to the following groups:
Pos: 53 /A nl eitu nge n/El ek tro nik/FU u nd S tart er/ 1. Allg emei n es/T ypens chl üss el/ Ty pensc hlü ssel /N o menkl atur _Er gä nzung L eng ende [SK 2xx E] @ 7\mod_1434028598383_388.docx @ 224310 @ @ 1
1
Frequency inverter
5
Optional module
2
Connection unit
6
Connection unit
3
Motors
7
Wall-mounting kit
4
Gear units
Pos: 54 /A nl eitu nge n/El ek tro nik/FU u nd S tart er/ 1. Allg emei n es/T ypens chl üss el/ Ty pensc hlü ssel /N o menkl atur _T ype nsc hild [SK 1x xE, SK 2 xxE] @ 6\mod_1431009774458_388.docx @ 217084 @ 3 @ 1
1.8.1 Name plate
All of the information which is relevant for the device, including information for the identification of the
device can be obtained from the type plate.
Legend
Type:
Type / designation
Part No.:
Part Number
ID:
Device ident number
FW:
Firmware version (x.x Rx)
HW:
Hardware version (xxx)
Figure 3: Name plate
