Page #159 background imageLoading...
Page #159 background image
5 Parameter
BU 0200 en-3118 159
Pos: 39 0 /Anlei tung en/El ektr onik/FU und Star ter /5. Par a meter/ Par a meter auf list ung (P0 00 . ..) /P3 00- P399/ Para meter P3 25 – Funktion Drehgeber [SK 2xxE] @ 2\mod_1347350750348_388.docx @ 44800 @ @ 1
P325
Rotary encoder function
(Rotary encoder function)
S
0 ... 4
{ 0 }
The actual speed list value supplied by an incremental encoder to the FI can be used for various
functions in the FI.
0 = Speed measurement Servom, "Servo mode speed measurement": The actual motor speed
list value is used for the FI servo mode. The ISD control cannot be switched off in this
function.
1 = PID actual frequency value: The actual speed of a system is used for speed control. This
function can also be used for controlling a motor with a linear characteristic curve. It is also
possible to use an incremental encoder for speed control which is not mounted directly onto
the motor. P413 – P416 determine the control.
2 = Frequency addition: The determined speed is added to the actual setpoint value.
3 = Frequency subtraction: The determined speed is subtracted from the actual setpoint.
4 = Maximum frequency: The maximum possible output frequency / speed is limited by the
speed of the encoder.
Pos: 39 1 /Anlei tung en/El ektr onik/FU und Star ter/5 . Par ameter/ Par ameter aufli stung (P000 ...) /P300- P399 /Para meter P326 – Drehgeber Übersetzung [SK 2xxE] @ 2\mod_1347350822183_388.docx @ 44824 @ @ 1
P326
Ratio encoder
(Encoder transformation ratio)
S
0.01 ... 100.0
{ 1.00 }
If the incremental encoder is not
mounted directly onto the motor shaft, then the respectively
correct transformation ratio of motor speed to encoder speed must be set.
speed Encoder
speed Motor
P326 =
Only when P325 = 1, 2, 3 or 4, therefore not in Servo mode (motor speed control)
Pos: 39 2 /Anlei tung en/El ektr onik/FU und Star ter/5 . Par ameter/ Par ameter aufli stung (P000 .. .)/P3 00-P3 99/Par amet er P327 – Schlep pf ehler Dre hz ahlr egl er [ SK 2 xxE ] @ 2\ mod_1347350884737_388.docx @ 44848 @ @ 1
P327
Speed slip error
(Speed slip error, speed control)
S P
0 ... 3000 rpm
{ 0 }
The limit value for a permitted maximum slip error can be set. If this value is reached, the FI
switches off and indicates error E013.1.
The slip error monitoring functions both with active and
inactive servo mode (P300).
0 = OFF
Only when P325 = 0, therefore in Servo mode (motor speed control).
(see also  P328)
Pos: 39 3 /Anlei tung en/El ektr onik/FU und Star ter/5 . Par ameter/ Par ameter aufli stung (P000 .. .)/P3 00-P3 99/Par amet er P328 – Verzög eru ng Sc hl eppf ehl er [ SK 2 xxE ] @ 2 \mod_1347350948150_388.docx @ 44872 @ @ 1
P328
Speed slip delay
(Speed slip error delay)
S P
0.0 ... 10.0 sec
{ 0.0 }
If the permissible speed slip error defined in (P327) is exceeded the
error message E013.1 is
suppressed within the time limits which are set here.
0.0 = OFF
