P555
Chopper P limitation
(Chopper power limitation)
S
5 ... 100 %
{ 100 }
With this parameter it is possible to program a manual (peak) power limit for the brake resistor.
The switch-on delay (modulation level) for the chopper can only rise to a certain maximum
specified limit. Once this value has been reached, irrespective of the level of the link voltage, the
inverter switches off the current to the resistor.
The result would be an overvoltage switch-off of the FI.
The correct percentage value is calculated as follows:
%100*
*
[%]
2
max
max
U
PR
k
BW
=
R = Resistance of the brake resistor
P
maxBW
= Momentary peak power of the brake resistor
U
max
= FI chopper switching threshold
1~ 115/230 V
⇒ 440 V=
3~ 230 V
⇒ 500 V=
3~ 400 V
⇒ 1000 V=
Pos: 54 1 /Anlei tung en/El ektr onik/FU und Star ter/5 . Par ameter/ Par ameter aufli stung (P000 .. .)/P5 00-P599/Parameter P555_P557 – Inform ati on [ SK 2 xxE] @ 21\ mod_1528461024571_388.docx @ 2425163 @ @ 1
Information
• Use of an external braking resistor: DIP switch S1:8: Setting „0“ (Off). Set the parameter
according to the braking resistor which is used.
• Use of an internal braking resistor: DIP switch S1:8: Setting „I“ (On). Settings in the
parameter do not have any effect.
(chapter
2.3.2) (chapter 2.3.1) (chapter 4.3.2.2)
Pos: 54 2 /Anlei tung en/El ektr onik/FU und Star ter/5 . Par ameter/ Par ameter aufli stung (P000 .. .)/P5 00-P5 99/Par amet er P556 – Brems widers tand @ 0\ mod_1328098726859_388.docx @ 12146 @ @ 1
P556
Braking resistor
(Brake resistor)
S
20 ... 400 Ω
{ 120 }
Value of the brake resistance for the calculation of the maximum brake power to protect the
resistor.
Once the maximum continuous output (P557) including overload (200 % for 60 s) is reached, an
I
2
t limit error (E003.1) is triggered. Further details in (P737).
Pos: 54 3 /Anlei tung en/El ektr onik/FU und Star ter/5 . Par ameter/ Par ameter aufli stung (P000 .. .)/P5 00-P599/Parameter P555_P557 – Inform ati on [ SK 2 xxE] @ 21\mod_1528461024571_388.docx @ 2425163 @ @ 1
Information
• Use of an external braking resistor: DIP switch S1:8: Setting „0“ (Off). Set the parameter
according to the braking resistor which is used.
• Use of an internal braking resistor: DIP switch S1:8: Setting „I“ (On). Settings in the
parameter do not have any effect.
(chapter
2.3.2) (chapter 2.3.1) (chapter 4.3.2.2)
Pos: 54 4 /Anlei tung en/El ektr onik/FU und Star ter/5 . Par ameter/ Par ameter aufli stung (P000 .. .)/P5 00-P5 99/Par amet er P557 – Leistung Bremswiderstand @ 0\mod_1328098773656_388.docx @ 12169 @ @ 1
P557
Brake resistor type
(Brake resistor power)
S
0.00 ... 20.00 kW
{ 0.00 }
Continuous power (nominal power) of the resistor, to display the actual utilisation in (P737
). For a
correctly calculated value, the correct value must be entered into (P556) and (P557).
0.00 = Monitoring disabled
Pos: 54 5 /Anlei tung en/El ektr onik/FU und Star ter/5 . Par ameter/ Par ameter aufli stung (P000 .. .)/P5 00-P599/Parameter P555_P557 – Inform ati on [ SK 2 xxE] @ 21\ mod_1528461024571_388.docx @ 2425163 @ @ 1
Information
• Use of an external braking resistor: DIP switch S1:8: Setting „0“ (Off). Set the parameter
according to the braking resistor which is used.
• Use of an internal braking resistor: DIP switch S1:8: Setting „I“ (On). Settings in the
parameter do not have any effect.
(chapter
2.3.2) (chapter 2.3.1) (chapter 4.3.2.2)
