6 Operating status messages
BU 0540 EN-1516 49
E003
3.0
I
2
t overcurrent limit
a.c. inverter: I
2
t limit has triggered, e.g. > 1.5 x I
n
for 60s
(also note P504)
Continuous overload at inverter output
Possible encoder fault (resolution, defect,
connection)
3.1 Chopper overtemperature I
2
t
Brake chopper: I
2
t limit has activated, 1.5 times values
reached for 60s (please also pay attention to P554, if
present, and P555, P556, P557)
Avoid overcurrent in brake resistance
3.2 IGBT overcurrent
125% monitoring
De-rating (power reduction)
125% overcurrent for 50ms
Brake chopper current too high
for fan drives: enable flying start circuit (P520)
3.3 IGBT overcurrent fast
150% monitoring
De-rating (power reduction)
150% overcurrent
Brake chopper current too high
Pos: 45 3 /Anlei tung en/El ektr onik/FU und Star ter/6 . Meld ungen zum Betr iebsz usta nd/Stör m eld ung en (A ufli st ung)/ Fehl er E0 04 [ SK 1 80E/ SK 2xx E/S K 5 xxE] @ 2\mod_1347453306910_388.docx @ 46501 @ @ 1
E004
4.0 Overcurrent module
Error signal from module (short duration)
Short-circuit or earthing fault at FI output
Motor cable is too long
Use external output choke
Brake resistor faulty or resistance too low
Do not shut off P537!
The occurrence of a fault can significantly shorten the
service life of the device, or even destroy it.
4.1 Overcurrent measurement
"Overcurrent measurement"
P537 (pulse current switch-off) was reached 3x within 50 ms
(only possible if P112 and P536 are disabled)
FI is overloaded
Drive sluggish, insufficiently sized
Ramps (P102/P103) too steep -> Increase ramp time
Check motor data (P201 … P209)
Pos: 454 /Anl eit ung en/El e ktroni k/F U und Star ter /6. M el dung en zum Betr ie bsz usta nd/ Stör mel dung en (A ufli stung )/F ehl er E 005 [ SK 1 80E/ SK 2xxE/SK 5xxE] @ 2\mod_1347453309234_388.docx @ 46526 @ @ 1
E005
5.0 Overvoltage UZW
Link circuit voltage too high
Increase deceleration time (P103)
If necessary, set switch-off mode (P108) with delay
(not with lifting equipment)
Extend emergency stop time (P426)
Fluctuating speed (e.g. due to high centrifugal
masses) adjust U/f characteristic curve if
necessary (P211, P212)
Devices with brake chopper:
Reduce energy return using a braking resistor
Check the function of the connected braking resistor
(broken cable)
Resistance value of connected braking resistor too
high
5.1 Mains overvoltage
Mains voltage is too high
See technical data ( Section 7)
Pos: 45 5 /Anlei tung en/El ektr onik/FU und Star ter/6 . Meld ungen zum Betr iebs zus ta nd/S tör mel dung en (Auf list ung )/F ehl er E 006 [SK 5x xE, SK2 xxE ] @ 2 \mod_1361458416246_388.docx @ 58807 @ @ 1
E006
6.0 Charging error
Link circuit voltage is too low
Mains voltage too low
See technical data ( Section
7)
6.1 Mains undervoltage
Mains voltage too low
See technical data ( Section 7)
Pos: 456 /A nleit ung en/El e ktr onik /FU und Star ter /6. M eldung en zu m B etrie bsz ust and /Stör m eld ung en (A ufli st ung)/ Fehl er E0 07 [ SK 1 35E, S K 20 0E, SK 5 00E ] @ 2\mod_1361460459184_388.docx @ 58907 @ @ 1
