SK 500E – Brief instructions for frequency inverters
50 BU 0540 EN-1516
E007
7.0 Mains phase error
Error at terminal connection side
• a network phase is not connected
• network is non-symmetrical
Pos: 457 /A nleit ung en/El e ktr onik /FU und Star ter /6. M eldung en zu m B etrie bsz ust and /Stör m eld ung en (A ufli st ung)/ Fehl er E0 08 [ SK 5 xxE] @ 2\mod_1361520584868_388.docx @ 58966 @ @ 1
E008
8.0 Parameter loss
(maximum EEPROM value
exceeded)
Error in EEPROM data
• Software version of the stored data set not
compatible with the software version of the FI.
NOTE: Faulty parameters are automatically reloaded
(default data).
• EMC interferences (see also E020)
8.1 Inverter type incorrect
• EEPROM faulty
8.2 External copying error
(ControlBox)
• Check ControlBox for correct position.
•
ControlBox EEPROM faulty (P550 = 1).
8.3 EEPROM KSE error
(Customer interface incorrectly
identified (customer’s interface
equipment))
The upgrade level of the frequency inverter was not
correctly identified.
• Switch mains voltage off and on again.
8.4 Internal EEPROM error
(Database version incorrect)
8.5 No EEPROM recognised
8.6 EEPROM copy used
8.7 EEPROM copy not the same
8.8. EEPROM is empty
8.9 EEPROM Ctrlbox too small
•
The EEPROM of the ControlBox is too small to
completely save the data set for the frequency
inverter
Pos: 458 /A nleit ung en/El e ktr onik /FU und Star ter /6. M eldung en zu m B etrie bsz ust and /Stör m eld ung en (A ufli st ung)/ Fehl er E0 09 [ SK 5 xxE] @ 2\mod_1361521138476_388.docx @ 58991 @ @ 1
E009
---
Display in ParameterBox not
required
ControlBox error/ SimpleBox error
SPI Bus faulty, no communication with ControlBox /
SimpleBox
• Check ControlBox for correct position.
• Check correct cabling of SimpleBox.
• Switch mains voltage off and on again.
Pos: 45 9 /Anlei tung en/El ektr onik/FU und Star ter/6 . Mel dung en zum Bet rie bsz ust and /Stör m eldung en (A ufli stung )/F ehl er E0 10 [ SK 5 00E ... SK 535E ] @ 2\ mod_1361522985031_388.docx @ 59041 @ @ 1
E010
10.0 Bus Timeout
Telegram time-out / Bus off 24V int. CANbus)
Data transfer is faulty. Check P513.
• Check external Bus connection.
• Check the program sequence of the Bus protocol
• Check Bus Master.
• Check 24V supply of internal CAN/CANopen Bus.
• Nodeguarding error (internal CANopen)
• Bus Off error (internal CANbus)
10.2 Bus Timeout Option
Bus module telegram timeout
• Telegram transfer is faulty.
• Check external connection.
• Check bus protocol program sequence.
• Check Bus Master.
10.4 Init error Option
Bus module initialisation failure
• Check Bus module power supply.
• Check P746.
• Bus module not correctly plugged in.
10.1 System error option
Bus module system error
