6 Operating status messages
BU 0540 EN-1516 51
10.3
• Further details can be found in the respective
supplementary Bus operating instructions.
10.5
10.6
10.7
10.8 Option error
External module communication failure
• Connection fault / error in the external module
• Brief interruption (<1sec) of the 24 V supply of the
internal CAN/CANopen bus
Pos: 461 /A nleit ung en/El e ktr onik /FU und Star ter /6. M eldung en zu m B etrie bsz ust and /Stör m eld ung en (A ufli st ung)/ Fehl er E011 [SK 180E ... SK 5xxE] @ 2\mod_1347453318765_388.docx @ 46626 @ @ 1
E011
11.0 Customer interface
Error in analog-digital converter
• Internal customer unit (internal data bus) faulty or
damaged by radio radiation (EMC)
• Check control terminals connection for short-circuit.
• Minimize EMC interference by laying control and
power cables separately.
• Earth the devices and shields well.
Pos: 462 /A nleit ung en/El e ktr onik /FU und Star ter /6. M eldung en zu m B etrie bsz ust and /Stör m eld ung en (A ufli st ung)/ Fehl er E0 12 [ SK 5x xE] @ 2\mod_1361524186547_388.docx @ 59066 @ @ 1
E012
12.0 External watchdog
The Watchdog function is selected at a digital input and the
impulse at the corresponding digital input is not present for
longer than the time set in parameter P460 >Watchdog
time<.
• Check connections
• Check P460 setting
12.1 Motor limit
"Motor switch-off limit"
The motor switch-off limit P534 [-01] has triggered.
• Reduce load on motor
• Set higher value in (P534 [-01]).
12.2 Generator limit
"Generator switch-off limit"
The generator switch-off limit P534 [-02] has triggered.
• Reduce load on motor
• Set higher value in (P534 [-02]).
12.5 Load limit
Switch-off due to overshooting or undershooting of
permissible load torques ((P525) … (P529)) for the time set
in (P528).
• Adjust load.
• Change limit values ((P525) ... (P527)).
• Increase delay time (P528).
• Change monitoring mode (P529).
12.8 Analog In minimum
Switch-off due to undershooting of the 0% adjustment value
(P402) with setting (P401) "0-10V with switch-off on error 1"
or "....2"
12.9 Analog In maximum
Switch-off due to overshooting of the 100% adjustment
value (P402) with setting (P401) "0-10V with switch-off on
error 1" or "....2"
Pos: 463 /Anl eit ung en/El e ktroni k/F U und Star ter /6. M el dung en zum Betr ie bsz usta nd/ Stör mel dung en (A ufli stung )/F ehl er E 013 [ SK 2 00E ... SK 5 xxE] @ 2\mod_1347454271218_388.docx @ 46751 @ @ 1
