Supplementary Manual DeviceNet for NORDAC SK 200E
52 Subject to technical amendments BU 0280 GB
Parameter
{Factory setting}
Setting value / Description / Note Device Supervisor
Parameter
set
P546 … [-01]
...
… [-03]
Function Bus setpoint 1 ... 3
S P
0 ... 24
{ [-01] = 01 }
{ [-02] = 00 }
{ [-03] = 00 }
In this parameter, a function is allocated to the output setpoint during bus actuation.
NOTE: For further details, please refer to the description for P400.
… [-01] = Bus setpoint value 1
… [-02] = Bus setpoint value 2 (only for PPO Type 2 or 4)
… [-03] = Bus setpoint value 3 (only for PPO Type 2 or 4)
Possible values which can be set:
0 = Off
1 = Setpoint frequency (16 bit)
2 = Frequency addition
3 = Frequency subtraction
4 = Minimum frequency
5 = Maximum frequency
6 = PI process controller actual value
7 = PI process controller setpoint
8 = Actual frequency PID
9 = Actual PID frequency limited
10 = Actual PID frequency monitored
11 = Limiting torque current
12 = Torque current switch-off limit
13 = Limiting current
14 = Current switch-off limit
15 = Ramp time
16 = Lead torque (P214) multiplication
17 = Servo mode torque
18 = Curve travel calculator
19 = Digital In bits 0...7
20 = ...24 reserved for Posicon
