Supplementary Manual DeviceNet for NORDAC SK 200E
54 Subject to technical amendments BU 0280 GB
5.1.4 Information parameters (P700)
Parameter
{Factory setting}
Setting value / Description / Note Device Supervisor
Parameter
set
P700 Current error
0.0 ... 21.4 Current error present. Further details are described in the frequency inverter manual (BU0200).
SimpleBox: Descriptions of the individual error numbers can be found in the point Error
messages.
ParameterBox: Errors are displayed in plain text, further information can be found in the point
Error messages.
P701 ... [-01]
...
... [-05]
Last fault 1...5
0.0 ... 21.4 This parameter stores the last 5 faults. Further details are described in the frequency inverter
manual (BU0200).
With the SimpleBox the corresponding memory location 1...5 (Array parameter), must be
selected and confirmed with the ENTER key in order to read the stored error code.
P740 ... [-01]
…
... [-13]
Process data bus In
S
0000 ... FFFF (hex) This parameter provides information about the actual control word (STW) and the setpoints
(SW1-3) that are transferred via the bus systems.
For values to be displayed, a bus system must be selected in P509.
… [-01 ] = Control word
Control word, source from P509.
… [-02 ] = Setpoint 1 (P546)
… [-03 ] = Setpoint 2 (P547)
… [-04 ] = Setpoint 3 (P548)
Setpoint data from main setpoint P510 - 01.
… [-05 ] = Bus I/O In Bits (P480)
The displayed value depicts all Bus In Bit sources
linked with
or.
… [-06 ] = Parameter data In 1
… [-07 ] = Parameter data In 2
… [-08 ] = Parameter data In 3
… [-09 ] = Parameter data In 4
… [-10 ] = Parameter data In 5
Data during parameter transfer: Order label (AK),
Parameter number (PNU),
Index (IND), Parameter value (PWE 1/2)
… [-11 ] = Setpoint 1
… [-12 ] = Setpoint 2
… [-13 ] = Setpoint 3
Setpoint data from master function value
(Broadcast), if P509/510 = 4 (P502/P503)
