Programming an application
8.4 Configuring placement of the SoftDevice
If your application uses Bluetooth or ANT, you must program a SoftDevice in addition to the application.
Note:
If your application does not use a SoftDevice, you can skip this step.
If you are using a SES project from nRF5 SDK v14.2.0 or later, the placement of the SoftDevice is
already configured correctly and you can skip this step.
If your application requires a SoftDevice, the flash and SRAM position where the compiled binary will be
placed must be configured as follows:
1. In SES, right-click your project and select Edit Options.
2. Select Linker.
3. In the Section Placement Macros field, add values for FLASH_START and SRAM_START.
To find the correct values, check the Keil project that you imported (in Keil µVision, select Options for
Target > Target), or program the firmware with approximate values, run it, and check the log output in
the debug terminal for the recommended values.
For example, when running the ble_app_uart example application from nRF5 SDK v12.3.0 on PCA10028
with SoftDevice S130 v2.0.1, specify the section placement macros as shown:
1159720_163 v1.1
21

Nordic nRF5 Series: nRF52 Specifications

General

Processor	ARM Cortex-M4
Operating Voltage	1.7 V to 3.6 V
GPIO	Up to 32
Temperature Range	-40°C to +85°C
Security	ARM TrustZone CryptoCell 310
Package	QFN, WLCSP
RAM	64 KB
Bluetooth	Bluetooth 5
NFC	Yes
ADC	12-bit
Operating Frequency	64 MHz
Flash Memory	Up to 512 KB
