11
10
9. Remove the Seat Knob (26) from the Seat
Bracket (30) inside the Seat Carriage (24).
Next, set the Seat Carriage (24) on the Seat
Post (6). Then, insert the Seat Knob (26) upward
into the Seat Post, and tighten the Seat Knob
into the Seat Bracket (30) inside the Seat
Carriage.
9
26
24
6
13
58
B
30
4
10. While a second person holds the Console (13)
near the Upright (4), connect the Main Wire (58)
to the matching wire on the Console.
Next, insert the other wires (B) on the Console
(13) downward through the large opening in the
Upright (4).
Insert the excess wire into the Upright (4).
