Nordson 3000V Series - Connecting the Air Supply

Installation
A1-7
E 2000 Nordson Corporation
All rights reserved
41-3000V
Issued 5/00
A3EN-04-[3V-A-AAXP]-12
Follow this procedure to connect the air supply to units with piston
pumps. If your unit has a gear pump, which is motor-driven, you do not
need to connect air to your unit. To determine which kind of pump your
unit has, see Figure A 1-4.
If your unit has a gear pump, go to the next procedure, Installing Guns.If
your unit has a piston pump, complete this procedure.
4130687
Fig. A 1-4 Piston Pump (left) and Gear Pump (right)
