Parts
7-11
Part 1105120-03
E 2015 Nordson Corporation
System Cables
See Figure 7-4. Order the correct cable length for your system.
Item Part Description Quantity Note
1 775374 12-ft UNICABLE 1
1 775023 25-ft UNICABLE 1
1 775375 50-ft UNICABLE 1
1 775377 75-ft UNICABLE 1
1 775380 100 ft UNICABLE 1
2 1061134 12 ft CABLE, RF detector 1
2 775029 25 ft CABLE, RF detector 1
2 775050 50 ft CABLE, RF detector 1
2 775051 75 ft CABLE, RF detector 1
2 775052 100 ft CABLE, RF detector 1
3 775031 NETWORK CABLE, 6 ft 1
2
3
1
Figure 7-4 System Cables
