Nordson DuraBlue D4L Customer Product Manual

Parts
7-5
Part 1032059B
E 2003 Nordson Corporation
Manual 41-DURABLUE-MA-02
Thermostat, Heaters, and RTDs
Item Part Description Quantity Note
— 1028321 Service kit, thermostat, —
NS - - - - - -
S Thermostat, 00R, 500 degree, open-on-rise
1
NS - - - - - -
S Screw, M4 x 6
2
NS - - - - - -
S Compound, thermal, 1 gram
1
— 1031223 Service kit, heater, pump, D4L — A
NS - - - - - -
S Heater assembly, 120 v, 350 W
1
— 1031224 Service kit, heater, pump, D4L — A
NS - - - - - -
S Heater assembly, 240 V, 350 W
1
— 1031227 Service kit, heater, pump, D10L/D16L — A
NS - - - - - -
S Heater assembly, 120 V, 300 W
1
— 1031228 Service kit, heater, pump, D10L/D16L — A
NS - - - - - -
S Heater assembly, 240 V 400 W
1
— 1031225 Service kit, heater, tank, D4L — A
NS - - - - - -
S Heater assembly, 120 V, 2 x 425 W
1
— 1031226 Service kit, heater, tank, D4L — A
NS - - - - - -
S Heater assembly, 240 V, 2 x 425 W
1
— 1031231 Service kit, heater, tank, D10L/D16L — A
NS - - - - - -
S Heater assembly, 120 V, 2 x 450 W
1
— 1031229 Service kit, heater, tank, D10L — A
NS - - - - - -
S Heater assembly, 240 V, 2 x 650 W
1
— 1031230 Service kit, heater, tank, D16L — A
NS - - - - - -
S Heater assembly, 240 V, 2 x 900 W
1
— 1031233 Service kit, RTD, pump — A
NS - - - - - -
S Sensor assembly, RTD
1
— 1031234 Service kit, RTD, tank — A
NS - - - - - -
S Sensor assembly, RTD and thermostat
1
NOTE A: All heater and RTD service kits include thermal compound.
NS: Not Shown
Ribbon Cables
Item Part Description Quantity Note
NS 1026662 Cable assembly, ribbon, 34-position, 3 headers — A
NOTE A: Connects the CPU to the main board.
NS: Not Shown
